Self-Loading Concrete Mixer
SDSG self-loading concrete mixers (also known as mobile concrete mixer trucks) combine an aggregate loading bucket, a weighing batcher and a rotating mixing drum on one full-time 4WD chassis, so a single operator can load, batch, mix and pour concrete on site — no separate batching plant or mixer truck required. The range spans 1.0 to 5.0 m³ of mixed output per batch, powered by turbocharged Yunnei, Yuchai and Weichai diesel engines (37–92 kW). Larger models add a 270° rotating drum for flexible discharge. Front/rear cameras, a digital dashboard, timed water feed and dual-circuit air brakes come standard; electronic weighing, heating/cooling A/C and a cement hopper are optional.
Price range: 9,900–30,200 USD
Key Features
- Self-loading, self-batching and mixing — one machine replaces a batching plant and a mixer truck
- Mixed output from 1.0 to 5.0 m³ per batch
- Full-time 4WD chassis built for rough, off-road job sites
- Turbocharged Yunnei / Yuchai / Weichai diesel engines, 37–92 kW
- Hydraulic loading bucket (0.25–0.75 m³) scoops aggregate straight into the drum
- 270° rotating drum on larger models for flexible discharge positioning
- Dual-circuit air brakes, front/rear cameras, digital dashboard and timed water feed as standard
Applications
Self-Loading Concrete Mixer — Specifications
| Model | Output | Loading bucket | Power | Weight |
|---|---|---|---|---|
| SLM-10 | 1.0 m³ | 0.25 m³ | 37 kW | 3100 kg |
| SLM-15 | 1.5 m³ | 0.55 m³ | 58 kW | 4500 kg |
| SLM-20 | 2.0 m³ | 0.65 m³ | 76 kW | 6600 kg |
| SLM-26 | 2.6 m³ | 0.65 m³ | 78 kW | 6800 kg |
| SLM-30 | 3.0 m³ | 0.65 m³ | 85 kW | 7335 kg |
| SLM-35 | 3.5 m³ | 0.65 m³ | 85 kW | 8300 kg |
| SLM-40 | 4.0 m³ | 0.65 m³ | 91 kW | 8600 kg |
| SLM-50 | 5.0 m³ | 0.75 m³ | 92 kW | 10,800 kg |
Specifications
| Mixed output per batch | 1.0 – 5.0 m³ |
|---|---|
| Drum (geometric) capacity | 1.3 – 8.28 m³ |
| Loading bucket | 0.25 – 0.75 m³ |
| Engine | Yunnei / Yuchai / Weichai turbo diesel |
| Engine power | 37 – 92 kW |
| Drive | Full-time 4WD |
| Drum rotation | Up to 270° (larger models) |
| Brakes | Dual-circuit air brakes |
| Max. travel speed | ≤ 35 km/h |
| Gradeability | Up to 40° |
| Water tank | 400 – 1100 L |
